    VRC - 9,375 to 15,625 Clips Magazine 2,000 Lbs.(2,500 Lbs. Crated) VRC Machine
    Print Printer Friendly Version  Email to a friend Displaying product images/PreviousPageIcon.gif 2 of 2
    Click to Enlarge
    Click to Enlarge
    Features and Benefits
    • Used in conjunction with the coil clip system for clipping borderwire to sides of inner spring assemblies
    • Clipping speed for Bonnel/Offset Bonnel and LFK coil assemblies is faster than previous VRC models. A single machine will now easily keep up with an experienced operator on the coil clip system.
    • The process of clipping an innerspring is as follows: An innerspring is taken off the transfer/coiler by an operator and placed on the Rotating Work table. The operator retrieves two border wires and positions them on the innerspring. They are attached to the perimeter corner coils using Clip Tool. The unit is now pre-clipped and is taken off the table and placed on the VRC Machine. The operator presses the start button and the machine runs automatically to finish attaching the border wires. While the machine clips the border wires the operator pre-clips another unit. The NEW faster VRC will finish clipping at the same time the operator finishes the second pre-clipping operation. The next pre-clipped unit is placed on the right side of the machine, the machine is started and the first finished unit is unloaded.
    • CE complaint option available
    • Programmable in English and Spanish.

    Product Details
    Weight 2000 lbs, 907.2 kilos
    Magazine Capacity 9,375 to 15,625
      Borderwire sides to innersprings
